8.4.1 Writingthedatatothedownloadjig(PWA-DWNLD-JIG2)
Thedownloadjig(PWA-DWNLD-JIG2)isthatinwhichtheFlashROMismountedontheboard
directly.TheROMwriteradapter(PWA-DL-ADP-350)isrequiredtowritedatatotheseFlash
ROMs.ConnectthedownloadjigwiththeROMwriterviaROMwriteradaptertowritedata.For
theproceduretowritedata,refertothedownloadingprocedure,instructionmanualofeach
ROMwriter,orothersources.
[1]
[2]
[4]
[3]
Fig.11-3
[1] PC
[2]Downloadjig(PWA-DWNLD-JIG2)
[3]ROMwriteradapter(PWA-DL-ADP-350)
[4] ROM writer
Notes:
There are two types of the ROM writer adapter. Use the proper one according to the ROM
writer to be used. Applicable type of the adapter for the ROM writer can be confirmed by the
model name indicated on the board. Confirm that the adapter is available for the ROM writer
tobeusedbeforeconnectingthem.Ifanunappliedadapterisconnected,theapplicationof
theROMwriterjudgesitasanerrorandwritingthedatacannotbeimplemented.Applicable
combinations of the ROM writer and adapter are as follows.
ROM writer ROM writer adapter
MinatoElectronicsMODEL1881XP/1881UXP
(orequivalent)
PWA-DL-ADP-350-1881(model1881)
MinatoElectronicsMODEL1893/1895/1931/1940
(orequivalent)
PWA-DL-ADP-350-1931-LV640(model
1931)
model 1881
[
PWA-DL-ADP-350-1881
]
model 1931
(
LV650
)
[
PWA-DL-ADP-350-1931-LV640
]
Fig.8-15 Fig.8-16
