[EA40] Side cover open jam
Classification Error content
Paperjaminnishersection Jam occurred because finisher’s side cover was opened while finisher
was transporting paper.
Check item Measures
Transport path Ifthereispaperinthepapertransportpath,removethepaper.
Side cover Close the cover if it is open.
Door switch • Switchcheck(SW2)
• Connectorcheck(P2-12,P2-13)
• Harnesscheck
Finisher control PC board • Boardcheck
• Connectorcheck(J2)
• Harnesscheck
Parts to be replaced Remark
Door switch
Finisher control PC board
[EA50] Stapling jam
Classification Error content
Paperjaminnishersection Staplejamoccurredatstapler.
Check item Measures
Stapler • Removethestaplecartridge,removeanyjammedstaples,installthe
staple cartridge.
• Connectorcheck(P9-1,P10-1)
• Harnesscheck
Finisher control PC board • Boardcheck
• Connectorcheck(J9,J10)
• Harnesscheck
Parts to be replaced Remark
Stapler
Finisher control PC board
