45641001TH Rev.1

5-41 /

Oki Data CONFIDENTIAL

Proce-

dure

Check item Measures

3 Board check • CheckiftheconnectorCN118,CN119ontheSYSboardandthe

connectorCUIF0,CUIF1onthePUboardarecompletelyinserted.

• CheckiftheconnectorpinbetweentheSYSboard(connectorCN118,

CN119)andthePUboard(connectorCUIF0,CUIF1)isdisconnected.

• CheckiftheconnectorsHEAD0K,HEAD1Y,HEAD2M,andHEAD3C

oftheLEDheadarecompletelyinserted,andtheharnessis

disconnected or open circuited.

• CheckiftheconductorpatternsonthePUboardandSYSboardare

short circuited or open circuited

Parts to be replaced Remark

PU board

SYS board

LEDhead

HarnessofLEDhead

[F110] Communication error between System-CPU and Scanner-CPU

[F111] Scanner response abnormality

Classiﬁcation Error content

Communication

service call

[F110] Communication error between System-CPU and Scanner- CPU

[F111] Scanner response abnormality

Check item Measures

SU board • CheckiftheharnessconnectingtheSUboardandSYSboardis

disconnected or open circuited.

• CheckiftheconductorpatternontheSUboardisshortcircuitedor

open circuited.

SYS board Check if the conductor pattern on the SYS board is short circuited or open

circuited.

Parts to be replaced Remark

SU board

SYS board
