Output check (test mode 03)

Code Function Procedure

301 Modem test 2100Hz 2

302 Modemtest14.4KBPS(V17) 2

303 Modemtest9.6KBPS(V29) 2

304 Modemtest4.8KBPS(V27) 2

305 Modem test 300BPS 2

306 Modemtest1850Hz 2

307 Modem test 1650Hz 2

308 Modem test 1100Hz 2

309 Modem test 462Hz 2

310 Modem test 1300Hz 2

311 Modemtest33.6KBPS(V.34) 2

312 Modemtest28.8KBPS(V.34) 2

313 Modemtest24.0KBPS(V.34) 2

314 Modemtest16.8KBPS(V.34) 2

315 Dial test 10PPS 5

316 Dial test 20PPS 5

317 Dial test PB 5

318 Modemtest12.0KBPS(V.17) 2

319 Modemtest7.2KBPS(V.29) 2

320 Modemtest2.4KBPS(V.27ter) 2

321 FAXimagememorytest 2

322 CMLrelayON 2
