Oki MPS5502 Service Manual

45641001TH Rev.1
5-6 /
Oki Data CONFIDENTIAL
Error code Classification Contents Troubleshooting
F101_5 Other service
call
Partition mount error: The HDD cannot be connected
(mounted)causedbydamagetothe“/registration”
partition.
P.5-48
F101_6 Partition mount error: The HDD cannot be connected
(mounted)causedbydamagetothe“/backup”
partition.
P. 5-49
F101_7 Partition mount error: The HDD cannot be connected
(mounted)causedbydamagetothe“/imagedata”
partition.
P. 5-50
F101_8 Partition mount error: The HDD cannot be connected
(mounted)causedbydamagetothe“/storage”
partition.
P. 5-51
F101_9 Partition mount error: The HDD cannot be connected
(mounted)causedbydamagetothe“/encryption”
partition.
P. 5-52
F102 HDD start error: HDD cannot become ‘Ready’
state.
P. 5-53
F103 HDD transfer time-out: Reading/writing cannot be
performed in the specified period of time.
P. 5-53
F104 HDD data error: Abnormality is detected in the data
of HDD.
P. 5-53
F105 HDD other error P. 5-53
F106_0 ADI-HDD error: Illegal disk replacement detected
(ADI-HDD Exchange to SATA-HDD)
P. 5-53
F106_1 ADI-HDD error: HDD type detection error P. 5-54
F106_2 ADI-HDD error: ADI encryption key download
operation error
P. 5-54
F106_3 ADI-HDD error: ADI authentication Admin
Password generation error
P. 5-55
F106_4 ADI-HDD error: Authentication random number
generation error
P. 5-55
F106_5 ADI-HDD error: Authentication data transmission
error
P. 5-55
F109_0 Keyconsistencyerror:Consistencycheckoperation
error.
P. 5-56
F109_1 Keyconsistencyerror:SRAMencryptionAES
key data damage.
P. 5-56
F109_2 Keyconsistencyerror:SignatureCheckpublickey
damage.
P. 5-56
F109_3 Keyconsistencyerror:HDDencryptionparameter
damage.
P. 5-57
F109_4 Keyconsistencyerror:licensedatadamage. P.5-58
F109_5 Keyconsistencyerror:EncryptionkeyforADI-HDD
is damaged.
P. 5-59
F109_6 Keyconsistencyerror:Administratorpassworderror
for ADI-HDD authentication.
P. 5-60
F110 Communication
related service
call
Communication error between System-CPU
and Scanner-CPU
P. 5-41
F111 Scanner response abnormality P. 5-41
F112 Communication error between System-CPU and
Scanner-CPU detected by Scanner-CPU
P.5-42
