Page #99 background imageLoading...
Page #99 background image
45641001TH Rev.1
5-16 /
Oki Data CONFIDENTIAL
Error code
Message displayed in the
WebPagescreen
Contents Troubleshooting
3D10 SMTP Destination Error has
been detected in the received
mail. This mail was deleted.
Destination address error P.5-78
3D20 Offramp Destination
limitation Error has been
detected in the received mail.
Offramp destination limitation error P.5-78
3D30 Fax Board Error has been
occurred in the received mail.
FAXboarderror P.5-78
3E10 POP3 Connection Error
has been occurred in the
received mail.
POP3 server connection error P.5-78
3E20 POP3 Connection Timeout
Error has been occurred in
the received mail.
POP3 server connection time-out error P.5-78
3E30 POP3LoginErrorhasbeen
occurred in the received mail.
POP3 login error P.5-78
3E40 POP3LoginErroroccurred
in the received mail.
POP3 login method error P.5-78
3F10 File I/O Error has been
occurred in this mail. The
mail could not be received
until File I/O is recovered.
File I/O error P.5-78
3F20 P.5-78
