62
TUBE A
5
3
1
2
4
Gas at
atmospheric
pressure
TUBE B
Figure 81. How to connect LEO during a calibration in Aspiration Mode.
13.2.3 Span Setting
Press Span Calibration icon to access to the Span Calibration submenu (see Figure 82 a).
a b
Figure 82. Span gas setting page (a – b).
To set all parameters of the span gas used to calibrate the CO2-O2-MODULE follow the instructions below:
1. Press Span Setting icon in the page that opens (see Figure 82 b) to access to the Span Settings
page.
