6-4 94MS20 Rev. B4
• SEE CHART FOR PROPER VOLTAGE READINGS (ALL
VOLTAGES ARE READ TO TERMINAL 3).
1.5kW with L1150A or L1150B LAMP
ORANGE YELLOW BLUE
a. IDLE/LOW 450+ 180 450+
b. HIGH 450+ 230 230
1.5kW with L1250E LAMP
ORANGE YELLOW BLUE
a. IDLE/LOW 450+ 180 450+
b. HIGH 450+ 230 230
2kW (AL25 and AL25-2 only) with L1250 LAMP
ORANGE YELLOW BLUE
a. IDLE/LOW 500+ 190 500+
b. HIGH 500+ 230 230
1.9kW and 2kW (other than AL25 and AL25-2) with L1150A LAMP
ORANGE YELLOW BROWN BLUE
a. IDLE 500+ 205 500+ 500+
b. LOW 500+ 190 500+ 500+
c. MEDIUM 500+ 210 210 500+
d. HIGH 500+ 225 225 225
1.9kW and 2kW with L1250E LAMP
ORANGE YELLOW BROWN BLUE
a. IDLE 500+ 210 500+ 500+
b. LOW 500+ 205 500+ 500+
c. MEDIUM 500+ 215 215 500+
d. HIGH 500+ 235 235 235
2.3kW with L1250 LAMP
ORANGE YELLOW BROWN BLUE
a. IDLE/LOW 500+ 190 500+ 500+
b. MEDIUM 500+ 210 210 500+
c. HIGH 500+ 235 235 235
