Olec OLITE - Page 61

94MS20 Rev. B4 6-5
2.3kW with L1252 LAMP
ORANGE YELLOW BROWN BLUE
a. IDLE/LOW 500+ 205 500+ 500+
b. MEDIUM 500+ 215 215 500+
c. HIGH 500+ 225 225 225
2.3kW with L1261 LAMP
ORANGE YELLOW BROWN BLUE
a. IDLE/LOW 500+ 210 500+ 500+
b. MEDIUM 500+ 215 215 500+
c. HIGH 500+ 225 225 225
3.5kW with L1250 LAMP
ORANGE YELLOW BROWN BLUE
a. IDLE/LOW 500+ 200 500+ 500+
b. MEDIUM 500+ 215 215 500+
c. HIGH 500+ 240 240 240
3.5kW with L1252 or L1261 LAMP
ORANGE YELLOW BROWN BLUE
a. IDLE/LOW 500+ 195 195 500+
b. HIGH 500+ 230 230 230
5kW with L1250 LAMP
ORANGE YELLOW BROWN BLUE #1 BLUE #2
a. IDLE/LOW 500+ 200 500+ 500+ 500+
b. MEDIUM 500+ 225 225 500+ 500+
c. HIGH 500+ 270 270 270 270
5kW with L1252 or L1261 LAMP
ORANGE YELLOW BROWN BLUE #1 BLUE #2
a. IDLE/LOW 500+ 200 500+ 500+ 500+
b. MEDIUM 500+ 230 230 500+ 500+
c. HIGH 500+ 270 270 270 270
