19. TROUBLE CODE Field Service Ver. 2.0 Jul. 2009
830
TROUBLESHOOTING
19.5.183 CC163: ROM contents error (PRT)
Relevant parts
Service EEPROM board (SV ERB) Printer control board (PRCB)
Step Action
WIRING DIAGRAM
Control signal
Location (Electri-
cal component)
1 Rewrite the firmware. — —
2 Change PRCB
1. Turn OFF the main power switch and
replace the current PRCB with a new
one.
(When using a PRCB of another
machine in service, be sure to use a
PRCB installed in the same model.)
See P.134
2. Update the PRCB firmware.
3. After completing the firmware update,
turn OFF and ON the main power switch
and check to see that warm-up is
started.
4. When the trouble cannot be solved, rein-
stall the removed PRCB to the original
board.
NOTE
• When taking the above steps, check
whether PRCB is defective or not
without replacing the SV ERB.
——
3 Change SV ERB
1. Replace the current SV ERB with a new
one.
See P.141
2. T
urn ON the main power switch and
check to see that warm-up is started.
(One minute is spent to prepare the new
SV ERB for use. During the period, the
control panel backlight stays off.)
3. Make the specified readjustments.
See P.141
——
4 If the above actions do not solve the prob-
lem, contact KMBT.
——
Service Manual Y110571-1
