19. TROUBLE CODE Field Service Ver. 2.0 Jul. 2009
832
TROUBLESHOOTING
19.5.186 CC170: Dynamic link error during starting (AP0)
19.5.187 CC171: Dynamic link error during starting (AP1)
19.5.188 CC172: Dynamic link error during starting (AP2)
19.5.189 CC173: Dynamic link error during starting (AP3)
19.5.190 CC174: Dynamic link error during starting (AP4)
19.5.191 CC180: Dynamic link error during starting (LDR)
19.5.192 CC181: Dynamic link error during starting (IBR)
19.5.193 CC182: Dynamic link error during starting (IID)
19.5.194 CC183: Dynamic link error during starting (IPF)
19.5.195 CC184: Dynamic link error during starting (IMY)
19.5.196 CC185: Dynamic link error during starting (SPF)
19.5.197 CC186: Dynamic link error during starting (OAP)
19.5.198 CC190: Outline font load error
Relevant parts
MFP board (MFPB) NVRAM board (NRB)
Step Action
WIRING DIAGRAM
Control signal
Location (Electri-
cal component)
1 If the malfunction code “C-C172” has
occurred, access [Service Mode] o [Sys-
tem 2] o [Image Controller Setting] and
check to see if “Controller 2,” “Controller 3,
or “Others” is set for [Image Controller Set-
ting].
If any of these is set, according to the kind
of controller, select “Controller 0” or “Con-
troller 1.
——
2 Change MFPB.
3 When not reviving even if the above-men-
tioned procedure is done, contact the
responsible people of KMBT.
——
Relevant parts
MFP board (MFPB) Hard disk
Step Action
WIRING DIAGRAM
Control signal
Location (Electri-
cal component)
1 Check the hard disk connector for proper
connection and correct as necessary.
——
2 Format hard disk.
3 Change hard disk
4 Change MFPB.
Service Manual Y110571-1
