Field Service Ver. 2.0 Jul. 2009 23. IC protector
911
TROUBLESHOOTING
23.2.5 ZU-606
A. ZU control board
23.2.6 FS-526
A. FS control board
ICP
Symbol
Symbol
Relevant parts
When ICP trips
Symptom in each load
Trouble code
and others
ICP1  DC5V sensor and others in the
board
Unable to be detected 
ICP3 M601 Registration motor Entrance JAM 
ICP4 M606 Main motor Folding section JAM 
ICP5 M605 Punch shift motor Punch shift motor drive malfunction C-1133
ICP6 M603 2nd stopper motor 2nd stopper motor drive malfunction C-1131
ICP7 M602 1st stopper motor 1st stopper motor drive malfunction C-1130
ICP8
SD601 Gate solenoid/Lw Main motor cooling fan drive mal-
function
C-1134
SD602 Gate solenoid/Up
CL601 Punch clutch
FM601 Main motor cooling fan
ICP9 M608 Punch switchover motor Punch switchover motor drive mal-
function
C-1136
ICP10 M604 Punch motor Punch motor drive malfunction C-1135
ICP12 M607 Punch scraps conveyance motor Punch scraps full 
ICP
Symbol
Symbol
Relevant parts
When ICP trips
Symptom in each load
Trouble code
and others
ICP1 M5 Main tray lift motor Main tray Up/Down motor malfunc-
tion
C-1102
ICP2 M4 Exit roller motor Paper exit roller drive motor malfunc-
tion
C-1104
SD1 Route change gate solenoid SD staple section JAM 
SD2 Bypass gate solenoid Bypass transport JAM 
SD3 Sub tray gate solenoid Sub tray exit JAM 
SD4 Switch back solenoid JAM during saddle stitch with paper
fed from PI

SD404 3rd Entrance switching solenoid Job tray paper exit JAM 
ICP3 M1 Transport motor/1 Entrance JAM 
M2 Transport motor/2 Entrance JAM 
Y110571-1 Service Manual
