3-30
Preparation before Use > Preparation for Sending a Document to a Shared Folder in a PC
2
Select the [File and Printer Sharing] checkbox.
Configuring Windows Firewall Settings
Permit sharing of files and printers and set the port used for SMB transmission.
1
Display the screen.
In charms on Desktop, click [Settings], [Control Panel], [System and Security], and then [Windows Firewall].
Log on to Windows with administrator privileges.
• In Windows Vista, from [Start] button on the Windows, select [Control Panel], [Security], and then [Turn
Windows Firewall on or off].
• In Windows 7: [Start] button > [Control Panel] > [System and Security] > [Check firewall status].
• In Windows 8: From the desktop charms: [Settings] > [Control Panel] > [System and Security] > [Windows
Firewall].
• In Windows 10: Start up Explorer. > [View] > [Options] > [Folder Options].
If the User Account Control dialog box appears, click the [Continue] button.
To Next Page
