12-2

Appendix > Optional Equipment

Optional Equipment

Overview of Optional Equipment

The following optional equipment is available for the machine.

(1)PF-470(2)PF-471

(3)IB-36

(4)Card Authentication Kit (B)

(8)IB-50

(7)HD-6/HD-7

(9)IB-51

(5)Fax System 13

(6)Expansion Memory
