Attaching the magnet sheet
a
b
Attach the magnet sheet corresponding to the units attached to
a
and
b
of the display pocket of the hand switch (BX3M-HS).
When the motorized or coded nosepiece is combined
Attach the magnet sheet corresponding to the objectives attached to
the OB indicator display pocket
a
of the hand switch.
When the coded reflected light illuminator (BX3M-URAS-S)
is combined
Attach the magnet sheet corresponding to the mirror units attached to
the CUBE indicator display pocket
b
of the hand switch.
The magnet sheet is provided with the hand switch (BX3M-HS).
When the coded reflected light illuminator (BX3M-RLAS-S)
is combined
Attach the magnet sheet to the CUBE indicator display pocket
b
of
the hand switch as shown in the picture.
