66 Specifications
Configuration units Product name Specifications
Microscope frame Reflected light
illumination only
BX53MRF-S Focusing unit:
Vertically movable stage
Movable range: 25 mm
Fine focusing knob: Moving distance per one rotation:
0.1mm
Coarse focusing knob: Moving distance per one rotation:
17.8 mm
Equipped with tension adjustment mechanism and
upper limit stopper mechanism
Rating:
AC adapter:
input: 100 - 240 V
50 - 60 Hz 0.4 A
output: 5 V 2.5 A
Microscope frame:
input: 5 V / 2.5 A
Maximum power consumption:
BX53MTRF-S: 10.1 W, 28.1 VA
BX53MRF-S: 5.8 W, 18.8 VA
Dimension: 275(W) x 363(D) x 310(H) mm
Weight: 7.8 kg
For both reflected
and transmitted
light illuminations
BX53MTRF-S
Observation tube Binocular tube U-BI30-2 Field number 22
U-TBI-3 Field number 22, tilting type
Trinocular tube U-SWTR-3 Field number 26.5
U-SWETTR-5 Field number 26.5, tilting type, for upright image observation
U-TR30-2 Field number 22
U-TR30IR Field number 22, for infrared observation
U-ETR-4 Field number 22, for upright image observation
U-TTR-2 Field number 22, tilting type
Illuminator for reflected light illumination BX3M-KMA-S For brightfield/DIC/simple polarization observations, built-in
LED light source
BX3M-RLA-S For brightfield/darkfield/DIC/simple polarization/infrared
observations
BX3M-RLAS-S For brightfield/darkfield/DIC/simple polarization observations,
coded type, built-in LED light source
BX3M-URAS-S For brightfield/darkfield/simple polarization/fluorescence/
infrared observations, coded type, detachable mirror unit
(attachable to 4 positions)
