4-11 Opening/Closing the shutter
1
This operation is necessary when the coded universal reflected
light illuminator (BX3M-URAS-S) is combined.
Push in the shutter to the second level (position where the clicking
sound is heard).
Shutter position Light path
First level (pulled out) OUT
Second level (pressed in) IN
