88
Operating environment
· Indoor use
· Altitude: Max. 2,000 meters
· Ambient temperature: 5 to 40 °C (41 to 104 °F)
· Maximum relative humidity: 80% for temperatures up to 31 °C (88 °F) (without condensation)
In case of over 31 °C (88 °F), the relative humidity is decreased linearly through 70% at 34 °C (93 °F),
60% at 37 °C (99 °F), and to 50% at 40 °C (104 °F).
· Supply voltage fluctuations: Not to exceed ±10% of the normal voltage.
· Pollution degree 2 (in accordance with IEC60664-1)
· Installation/Overvoltage category :
(in accordance with IEC60664-1)
Configuration units Product name Specifications
Stage U-SP Plain stage
U-SVRM
U-SVLM
Movable range: 52(Y) x 76(X) mm
Equipped with handle tension adjustment mechanism
U-SIC4R2
U-SIC4L2
Movable range: 100(Y) x 105(X) mm
Equipped with Y-axis lock mechanism
U-SIC64 Movable range:
Reflected light observation: 100(Y) x 150(X) mm
Transmitted light observation: 50(Y) x 100(X) mm
Equipped with handle tension adjustment mechanism
Equipped with Y-axis lock mechanism
Condenser for transmitted light
observation
U-AC2 Numerical aperture: 1.1
Working distance: 0.7 mm (oil immersion)
U-SC3 Swing-out top lens
Numerical aperture:
0.9 (when using the top lens)
0.171 (when swinging out the top lens)
Working distance: 2 mm (when using top lens)
U-POC-2 Swing-out top lens
Numerical aperture:
0.9 (when using the top lens)
0.18 (when swinging out the top lens)
Working distance : 1.3 mm (when the slide glass thickness is
1.5 mm)
U-LWCD Numerical aperture: 0.65
Working distance: 11.6 mm
