S
ETUP
part
2
Front Panel Annunciators
SP1 OUT1/Setpoint 1 indicator.
SP2 OUT2/Setpoint 2 indicator.
AL1 Alarm 1 indicator.
AL2 Alarm 2 indicator.
¡C ¡C unit indicator.
¡F ¡F unit indicator.
PV Upper display shows the Process Value
SV Lower display shows the Setpoint Value
MENU Changes display to Configuration Mode and advances thru menu items*
/MAX Used in program mode and peak recall*
/MIN Used in program mode and valley recall*
ENTER Accesses submenus in Configuration Mode and stores selected values*
* See Part 3 Operation:Configuration Mode
Figure 2.2 Front Panel Display
2.2. Front Panel View
