part
3
O
PERATION
: C
ONFIGURATION
M
ODE
52
Output 2
Display Action Response
Press MENU 1) Press MENU, if necessary, until the "
out 2
" prompt appears.
Press ENTER 2) Display advances to
"Control Type" submenu.
IF OUTPUT 2 IS NOT INSTALLED, THE CONTROLLER WILL SHOW "NOT INSTALLED"
Press MENU Press MENU, if the "not installed" message is displayed, advance to the "Ramp & Soak"
submenu.
CONTROL TYPE SUBMENU:
Press ENTER 3) Display flashes
"
0n . 0f
" or "
PId
".
Press MAX 4) Scroll through the available selections:
0n . 0f
or
PId
.
Press ENTER 5) Display flashes
"
strd
" message and advances to "Action Type" submenu.
The ON/OFF control is a coarse way of controlling the process. The "Dead Band" improves the cycling associated with the
On/Off control. The PID control is best for processes where the set point is continuously changing and/or tight control of the
process variable is required.
CTRL
PID
CTRL
TYPE
NoT
_
INST
oUT
2
