Omega MICROMEGA CN77000 series User Manual

part
3
O PERATION : C ONFIGURATION M ODE
COMMUNICATION COMMANDS (Table 3.1)
Command Prefix Meaning
(Command Class)
^AE Special read, Communication parameters
P (Put) Write HEX data into RAM
W (Write) Write HEX data into EEPROM. 1,000,000 writes to EEPROM is guaranteed!
G (Get) Read HEX data from RAM
R (Read) Read HEX data from EEPROM
U Read status byte
V Read measurement data string in decimal format
X Read measurement data values in decimal format
D Disable
E Enable
Z Reset
Command Formats
For ÒPÓ and ÒWÓ For ÒGÓ and ÒRÓ For ÒXÓ, ÒVÓ, ÒUÓ, ÒDÓ, ÒEÓ
Command Classes: Command Classes: and ÒZÓ Command Classes:
Point-to-point mode: * ccc [<data>] <CR> Point-to-point mode: * ccc <CR> Point-to-point mode: * ccc <CR>
Multipoint mode: * nnccc [<data>] <CR> Multipoint mode: * nnccc <CR> Multipoint mode: * nnccc <CR>
72
