O
PERATION
: C
ONFIGURATION
M
ODE
part
3
19
ID Number (if enabled)
Display Action Response
SEE ID OPTION SUBMENU IN THE BREAK LOOP ALARM SECTION FOR ENABLE/DISABLE ID OPTION
ENTERING OR CHANGING YOUR (NON-DEFAULT) ID NUMBER
Press MENU 1) Press MENU, if necessary, until "
ID C0DE
" prompt appears.
Press ENTER 2) Display advances to "
ID CD
", if non-default ID code. If default ID code, the menu
will advance to
CH.ID
with default value i.e. 0000.
If the ID code is the default value i.e. 0000, press MENU again and the menu will skip the
ID code to Set Point Menu.
Press MAX & MIN 3) Press MAX to increase digit 0-9. Press MIN to activate next digit (flashing).
Continue to use MAX and MIN to enter your 4-digit ID code.
Press ENTER 4) If the correct ID code is entered, the menu will display
CH.ID
, otherwise an error
message will be displayed and the controller will return to the Run Mode.
Press MENU 5) To leave your ID code Unchanged, press MENU and advance to "
SET PoNT
" Menu.
or
Press MAX & MIN To Change your ID code use the MAX and MIN buttons to enter a new ID code.
Press ENTER 6) Display flashes "
STRD
" message and advances to the next menu "
SET PoNT
".
To prevent unauthorized tampering with the setup parameters, the controller provides protection by requiring the user to enter the ID code
before allowing access to subsequent menus. If the ID code entered does not match the ID code stored, the controller responds with an
error message and access to subsequent menus will be denied.
STRD
1234
CK.ID
1234
ID.CD
____
Id
C0de
It is recommended that you put the controller in the Standby Mode
for any configuration change other than setpoints & alarms
