Omega MICROMEGA CN77000 series - Controller Installation; Mounting Procedures

part
2
S ETUP
4
2.1 Mounting the Controller
If necessary, the rear connector assembly may be removed from the main case for
wiring (see Figure 2.1a for Square Mount, Figure 2.1b for Round Mount).
R 0.06
[1.6]
Note
☞
