Rear Panel Connector Labels
POWER AC Power Connector: All models
INPUT Input Connector: All models
TC, PR (Process)
RTD
ALARM 1 ALARM 1 relay SPST, programmable: All models
OUTPUT 1 Control Output 1: Based on one of the following models.
Relay SPDT Voltage and Current
Solid State Relay Pulse
OUTPUT 2 Control Output 2: Based on one of the following models:
Relay SPST Normally Open
Solid State Relay
Pulse
OPTION Based on one of the following models:
RS-232C Isolated Analog Out
RS-485 Alarm 2 Relay SPST, programmable
Remote Setpoint
