S
ETUP
part
2
15
The figure shows the wiring hookup for Process
Current 0 - 20 mA.
When configuring your controller, select
Process type in the Input Type menu
(see part 3).
The figure shows the wiring hookup for
Process Voltage 0 - .1 V, 0 - 1 V, or 0 -10 V.
When configuring your controller, select
Process type in the Input Type menu
(see part 3).
Figure 2.5.5 Process Voltage Wiring Hookup
Figure 2.5.4 Process Current Wiring Hookup
2.5.4. Process Voltage
2.5.3. Process Current
