part
2
S
ETUP
10
2.4. Mechanical Installation
The settings of the DIP switch must be verified or set to comply with your
selection at the Input/Type menu (see Section 3.0 for Input/Type). The DIP
switch is accessible through an opening on the side of the case. After carefully
removing the controller from the case, see Section 2.1 for instructions, locate the dip
switch (see Figure 2.4) and set the switches according to the following tables.
Figure 2.4 Dip Switch Location Ñ switch settings are shown in OFF position
Dip Switch
Configuration
To Next Page
