O
PERATION
: C
ONFIGURATION
M
ODE
part
3
Input Type (Process)
Display Action Response
ENTER INPUT TYPE MENU:
Press MENU 1) Press MENU, if necessary, until
"
Inpt type
" prompt appears.
Press ENTER 2) Display flashes
"
rtd
", "
t.c
", or "
proc
" (RTD, Thermocouple, Process), if the
displayed input type is Process, press MENU to skip to step 5 (
proc
stops flashing).
PROCESS SUBMENU:
Press MAX 3) Press MAX to scroll to
"
Proc
" (flashing).
Press ENTER 4) Display flashes
"stored" message and "
Proc
" stops flashing.
Press ENTER 5) Display flashes previous Process type selection. ie.
"
0-10
" (See below for types.)
Press MAX 6) Scroll through the available Process types to the selection of your choice.
Press ENTER 7) Display flashes
"stored" message and advances to the next menu "Reading
Configuration
".
Use the Input Type (Thermocouple) (RTD) or (Process) and verify your Dip Switch Setting (see section 2.4) and your Electrical Installation
(see section 2.5). See the previous pages for (RTD) and (Process) menus.
Process Types: 100mV 1V 10V 0-20 mA
Display:
0-0.1 0-1.0 0-10 0-20
Natural Gain 100 cts/mv 10 cts/1mV 1 ct/mV 500 cts/mA
Max Display 9999 @100 mv 9999 @ 1V 9999 @ 10V 9999 @ 20 mA
For 4-20 mA Input select 0-20 mA and adjust the Input Scale & Offset accordingly. To adjust 4-20 mA input. (See example under INPUT
Scale & Offset.)
Proc
0-10
INPT
PRoc
INPT
TYPE
