O
PERATION
: C
ONFIGURATION
M
ODE
part
3
25
Input Type (RTD)
Display Action Response
ENTER INPUT TYPE MENU:
Press MENU 1) Press MENU, if necessary, until
"
Inpt type
" prompt appears.
Press ENTER 2) Display flashes
"
rtd
", "
t.c
", or "
proc
" (RTD, Thermocouple, Process), if the
displayed input type is
RTD
, press MENU to skip to step 5 (
rtd
stops flashing).
RTD SUBMENU:
Press MAX 3) Press MAX to scroll to
"
RTD
" (flashing).
Press ENTER 4) Display flashes
"stored" message and "
RTD
" stops flashing
Press ENTER 5) Display flashes previous RTD type selection ie. 392.2. (See below for RTD types.)
Press MAX 6) Scroll through the available RTD types to the selection of your choice:
Press ENTER 7) Display flashes
"
strd
" message and advances to "
rtd valU
".
RTD Types: 385, 392, Two, Three and Four-wire
Display:
392.2 392.3 392.4 385.2 385.3 385.4
Last digit indicates: 2, 3 or 4-wire input.
INPT
392.2
INPT
RTD
INPT
TYPE
