Omega MICROMEGA CN77000 series User Manual

O PERATION : C ONFIGURATION M ODE
part
3
33
Alarm 1
Display Action Response
Press MENU 1) Press MENU, if necessary, until "
Alar 1
" prompt appears.
Press ENTER 2) Display advances to
"
Alar.1 enbl
" or "
dsbl
" submenu.
ALARM 1 ENABLE/DISABLE SUBMENU:
Press MAX 3) Display flashes previous selection. Press MAX until
"
Enbl
" displays to use Alarm 1.
Press ENTER 4) Display flashes
"
strd
" message only if it was changed, otherwise press MENU to
advance to
"Control Type" submenu.
CONTROL TYPE SUBMENU:
Press MAX 5) Display flashes previous selection. Press MAX to
"
ABS
o
" or "
Dev
."
Press ENTER 6) Display flashes "
strd
" message only if it was changed, otherwise press MENU to
advance to
"Alarm 1 Latch" submenu.
Absolute Mode allows Alarm 1 to function independently from Setpoint 1. If the process being monitored does not change
often, then
"Absolute" Mode is recommended.
Deviation Mode allows changes to Setpoint 1 to be made automatically to Alarm 1. Deviation Mode is typically the ideal mode
if the process temperature changes often. In Deviation Mode, set Alarm 1 a certain number of degrees or counts away from
Setpoint 1 Ñ this relation remains fixed even if Setpoint 1 is changed.
ALR.1
ABSo
ALR.1
ENBL
ALAR
1
Note
☞
