O
PERATION
: C
ONFIGURATION
M
ODE
part
3
53
Output 2 cont.
Display Action Response
ACTION TYPE SUBMENU:
Press ENTER 6) Display flashes
"
drCt
" or "
rUrs
".
Press MAX 7) Scroll through the available selections: Direct or Reverse.
Press ENTER 8) Display flashes
"
strd
" message and advances to "Auto PID" submenu.
If
"ON/OFF" was selected in the Control Type, the display skips to the "Deadband"
submenu.
The error that results from the measurement of the process variable may be positive or negative since it may be greater or
smaller than the set point. If a positive error should cause the controller output to increase (i.e. cooling), it would be called
Direct Acting. If a negative error should cause the output to increase (i.e. heating), it would be called Reverse Acting.
ACTN
DRCT
ACTN
TYPE
