part
3
O
PERATION
: C
ONFIGURATION
M
ODE
54
Output 2 cont.
Display Action Response
AUTO PID SUBMENU:
Press ENTER 9) Display flashes
"
enbl
" or "
dsbl
".
Press MAX 10) Scroll through the available selections: Enable or Disable.
If
"Enabled", the PID parameter of Output 1 will be copied to Output 2.
Press ENTER 11) Display flashes
"
strd
" message and advances to the next submenu Ñ
If
"Auto PID" was "Enabled", the display skips to the "Cycle Time" submenu.
If
"Auto PID" was "Disabled", the display will show the "Proportional Band"
submenu allowing the user to manually enter the Proportional Band value.
The Reset and Rate value are the same as Output 1.
PROPORTIONAL BAND SUBMENU:
Press ENTER 12) Display flashes 1st digit of the previous
"Proportional Band" value.
Press MAX & MIN 13) Press MAX and MIN buttons to enter a new
"Proportional Band" value.
Press ENTER 14) Display flashes
"
strd
" message and advances to the "Cycle Time" submenu.
Refer to Proportional Band, submenu of Output 1 Menu.
PROP
BAND
AUTO
ENBL
AUTO
PID
To Next Page
