O
PERATION
: C
ONFIGURATION
M
ODE
part
3
55
Output 2 cont.
Display Action Response
CYCLE TIME SUBMENU:
Press ENTER 15) Display flashes 1st digit of the previous
"Cycle Time" value.
Press MAX & MIN 16) Press MAX and MIN buttons to enter a new
"Cycle Time" value. (1 to 199 seconds).
Press ENTER 17) Display flashes
"stored" message and advances to "Ramp & Soak" Menu.
A Cycle Time selected between 1 to 199 seconds indicates the total On/Off time of each proportional cycle. For example, a
15 second Cycle Time means that every 15 seconds the output will turn on for part or all of the cycle. For Relay control
outputs, do not select a cycle time of less than 7 seconds or the relays life time will be shortened. For a cycle time of less
than 7 seconds select SSR or DC pulse. Use an external SSR with the DC pulse option for higher current (higher than 1 Amp).
CYCL
0010
CYCL
TIME
To Next Page
