part
3
O
PERATION
: C
ONFIGURATION
M
ODE
56
Output 2 cont.
Display Action Response
The "Dead Band" submenu will only appear if the "On/Off" was selected from the
"Control Type" menu.
DEAD BAND SUBMENU:
Press ENTER 18) Display flashes 1st digit of the previous
"Dead Band" value.
Press MAX & MIN 19) Press MAX and MIN buttons to enter a new
"Dead Band" value.
Press ENTER 20) Display flashes
"stored" message and advances to the "Ramp Value" menu.
Refer to Dead Band submenu of Output 1 Menu.
The Dead Band is the number of degrees or counts around the setpoint which the process variable must pass through
before the output changes state.
DEAD
006.7
DEAD
BAND
To Next Page
