O
PERATION
: C
ONFIGURATION
M
ODE
part
3
Alarm 1 cont.
Display Action Response
ALARMS ENABLE/DISABLE AT POWER ON:
Press MAX 11) Display flashes previous selection. Press MAX to enable or disable.
If the alarm is enabled at Power On, the alarm will be active right after reset. If the alarm is
disabled at Power On, the alarm will become enabled when the process value enters the
non alarm area. The alarm is not active while the Process value is approaching Setpoint 1.
Press ENTER 12) Display flashes
"Stored" message only if it was changed, otherwise press MENU to
advance to the
"Alarm 1 Low Value" submenu.
ALARM 1 LOW VALUE SUBMENU:
Press MAX & MIN 15) Display flashes 1st digit of previous value. Use MAX and MIN to enter new value.
Press ENTER 16) Display flashes
"
strd
" message, only if it was changed, otherwise press MENU to
advance to
"Alarm 1 HI Value" submenu.
ALARM 1 HI VALUE SUBMENU:
Press MAX & MIN 17) Display flashes 1st digit of previous value. Use MAX and MIN to enter new value.
Press ENTER 18) Display flashes
"
strd
" message only if it was changed, otherwise press MENU to
advances to
"Alarm 2" submenu.
Latched Mode: Relay remains "latched" until reset. To reset a latched alarm, put unit into ÒStand-byÓ Mode by pressing the ENTER
button twice. Then, enter back into Run Mode by pressing the ENTER button a third time and alarm will be de-energized.
Unlatched Mode: Relay remains latched only as long as the alarm condition is true.
Normally Closed
:"Fail Safe" Mode, relay is energized under "normal" conditions and becomes de-energized during alarm or power failure.
Normally Open: If this feature is selected, then the relay is "energized" only when an alarm condition occurs.
AL1. H
2722
AL1.L
0762
A.P.oN
ENBL
