PLATINUM
TM
Series Controllers User’s Guide
M5451 Omega Engineering | www.omega.com
38
Reference Section: Initialization Mode (INIt)
6.4.5 Annunciator Settings (INIt > RdG > ANN.1/ANN.2)
Select the Annunciator 1 (ANN.1) parameter. This controls which Alarm or output status
activates the “1” annunciator on the front display. In general, the default values for both
annunciators should be used (status for Alarm configuration 1 for annunciator 1 and status for
Alarm configuration 2 for annunciator 2). However, it can be useful during troubleshooting to
map the on/off status of one or two outputs to the annunciators.
The ANN.1 and ANN.2 parameters work the same way except that they control the “1” and
the “2” front display annunciators, respectively, and have different default values.
Navigate to the desired setting. Settings include the following:
ALM.1 The configuration defined by PRoG > ALM.1 determines the state of the
annunciator. The annunciator turns on when the Alarm condition exists (factory
default for ANN.1).
ALM.2 The configuration defined by PRoG > ALM.2 determines the state of the
annunciator (factory default for ANN.2).
oUt# oUt# is replaced by a list of the names of all outputs that are not analog
outputs. For example, the output choices dtR.1 and dC.1 are listed for a “145”
configuration, and ANG.1 is not listed.
Select the indicated option.
6.4.6 Normal Color (INIt > RdG > NCLR)
Select the Normal Color (NCLR) parameter. This controls the default display color, which can
then be overridden by Alarms.
Navigate to the desired setting. Settings include the following:
GRN Green (factory default)
REd Red
AMbR Amber
Select the indicated option.
6.4.7 Brightness (INIt > RdG > bRGt)
Select the Brightness (bRGt) parameter.
Navigate to the desired setting. Settings include the following:
HIGH High display brightness (factory default)
MEd Medium display brightness
Low Low display brightness
Select the indicated option.
