PLATINUM
TM
Series Controllers User’s Guide
M5451 Omega Engineering | www.omega.com
66
Reference Section: Programming Mode (PRoG)
7.8.5 Program End Action (PRoG > M.RMP > E.ACT)
Select the End Action (E.ACT) parameter.
Navigate to the desired setting. Settings include the following:
StOP Enter standby mode displaying RUN at the completion of this program.
HOLd Hold at the final soak setpoint at the completion of this program.
LINk Link to another stored ramp & soak program at the completion of this
program.
o ## Specify the Program Number to start at the completion of this
program (1 to 99). Specifying 0 will repeat the program specified by S.PRG
which can provide for cycling through a series of linked programs. Specifying
100 will restart the last program run in a sequence of linked programs.
Select the indicated setting.
7.8.6 Number of Segments (PRoG > M.RMP > N.SEG)
Select the Number of Segments (N.SEG) parameter.
Set the number of segments (18). (The default is 1.)
Confirm the value.
7.8.7 Segment Number for Editing (PRoG > M.RMP > S.SEG)
Select the Segment Number for Editing (S.SEG).
Set the segment number to edit for the Program Number. This segment number selection will
replace the “#” digit in all of the ramp and soak control parameters for that segment listed
below (MRt.#, MSt.#, etc.), as viewed on the unit’s display. This will help keep track when
programming multiple ramp and soak segments from the front panel.
Confirm the segment number.
Navigate to the desired setting. Settings include the following:
MRt.# Time for Ramp number # (the default is 10). Ramp and Soak times can be
as long as either 99 minutes and 59 seconds or 99 hours and 59 minutes. The default
format is controlled by the tIM.F parameter setting for this program. The default can
be overridden for any segment time as described under tIM.F.
MRE.# Determine whether to activate Ramp-event-enabled outputs:
o oFF Disable Ramp events for this segment (factory default)
o oN Enable Ramp events for this segment. At least one output must be set
to MoDE = RE.oN for an enabled ramp event to actually do anything.
MSP.# Setpoint value for Soak cycle #
MSt.# Time for the Soak cycle (the default is 10). See MRT.# for more info.
MSE.# Determine whether to activate Soak-event-enabled outputs:
o oFF Disable Soak events for this segment (factory default)
o oN Enable Soak events for this segment. At least one output must be set
to MoDE = RE.oF for an enabled soak event to actually do anything.
Select the indicated setting.
