7.3.11 Alarm Off Delay (PRoG > ALM.1, ALM.2 > dE.oF)
Select the Alarm Off Delay (dE.oF) parameter.
Set the number of seconds to delay cancelling the Alarm. (The default is 0.) This setting can be
used to prevent Alarm chatter.
Confirm the value.
7.4 Output Channel 16 Configuration (PRoG > oUt.1oUt.6)
Navigate to the desired output channel. The number and type of output channels on the
PLATINUM
TM
Series are automatically recognized by the device. The following output names
display, replacing the generic oUt.1 through oUt.6 references used in this document:
StR1 Single Throw Mechanical Relay number 1
StR2 Single Throw Mechanical Relay number 2
StR3 Single Throw Mechanical Relay number 3
StR4 Single Throw Mechanical Relay number 4
dtR1 Double Throw Mechanical Relay number 1
dtR2 Double Throw Mechanical Relay number 2
SSR1 Solid State Relay number 1
SSR2 Solid State Relay number 2
SSR3 Solid State Relay number 3
SSR4 Solid State Relay number 4
dC1 DC Pulse output number 1
dC2 DC Pulse output number 2
dC3 DC Pulse output number 3
ANG1 Analog output number 1
IdC1 Isolated DC Pulse output number 1
IdC2 Isolated DC Pulse output number 2
IAN1 Isolated Analog output number 1
Note: All output channels have the same menu structure. However, only those parameters
that apply for the type of output being configured appear in that output’s menu.
Select the indicated output channel.
Navigate to the desired submenu. Submenus include the following:
ModE Allows the output to be set up as a control, Alarm, retransmission, or
Ramp/Soak event output; the output can also be turned off
CyCL PWM pulse width setting for DC pulse, mechanical relay, and solid state
relay outputs
RNGE Sets the voltage or current range for analog outputs
Select the indicated setting.
