41
Reference Section: Initialization Mode (INIt)
6.6.3 Serial Communications Parameters (INIt > CoMM > SER >C.PAR)
Select C.PAR. Then, select individual parameters to configure the serial communications.
Navigate to the correct setting. Settings include the following:
bUS.F Specify RS232 or RS485 serial communications
bAUd Baud rate (transmission rate)
PRty Parity (used for transmission error checking)
dAtA Number of bits per data point
StoP Number of stop bits between data points
Select the desired setting.
6.6.3.1 Serial Bus Format (INIt > CoMM > SER > C.PAR >
bUS.F)
Select the Bus Format (bUS.F) parameter.
Navigate to the desired setting. Settings include the following:
232C Allows one-to-one serial communications (factory default)
485 Allows multiple devices to operate on a single pair of wires
Select the indicated option.
6.6.3.2 Baud Rate (INIt > CoMM > SER > C.PAR > bAUd)
Select the Baud Rate (bAUd) parameter. The device being communicated to
determines how fast to set the Baud Rate.
Navigate to the desired setting for Baud rate (bits per second):
19.2 19,200 Baud (factory default)
9600 9,600 Baud
4800 4,800 Baud
2400 2,400 Baud
1200 1,200 Baud
57.6 57,600 Baud
115.2 115,200 Baud
Select the indicated option.
6.6.3.3 Parity (INIt > CoMM > SER > C.PAR > PRty)
Select the Parity (PRty) parameter.
Navigate to the desired setting. Settings include the following:
odd Odd parity used to verify communications (factory default)
EVEN Even parity used to verify communications
NoNE Parity is not used to verify communications
Select the indicated option.
