Specifications
Ramp and Soak
Up to 99 Saved Ramp and Soak programs
Up to 8 Ramp and 8 Soak segments with individually selectable
events per program
Definable End Actions include program linking
Ramp and Soak segment times: 00.00 to 99.59 (for HH:MM and
MM:SS)
9.3 Outputs
Analog
Non-Isolated, Proportional 010 Vdc or 0–20 mA; 500 Ω max. Programmable
for control or retransmission. Accuracy is 0.1% of full scale.
DC Pulse
Non-Isolated; 10 Vdc at 20 mA
SPST Relay
Single pole, single throw mechanical relay, 250 Vac or 30 Vdc at 3 A (Resistive
Load)
SPDT Relay
Single pole, double throw mechanical relay, 250 Vac or 30 Vdc at 3 A
(Resistive Load)
SSR
20265 Vac at 0.050.5 A (Resistive Load); continuous
Isolated DC Pulse
Isolated; 10 Vdc at 20 mA
Isolated Analog
Isolated, Proportional 010 Vdc or 0–20 mA; 500 Ω max. Programmable for
control or retransmission. Accuracy is 0.1% of full scale.
9.4 Communications (USB Standard, Optional Serial and Ethernet)
Connection
USB: Female Micro-USB, Ethernet: Standard RJ45, Serial: Screw terminals
USB
USB 2.0 Host or Device
Ethernet
Standards Compliance IEEE 802.3 10/100 Base-T Auto-switching, TCP/IP, ARP,
HTTPGET
Serial
Software Selectable RS/232 or RS/485. Programmable 1200 to 115.2 K baud.
Protocols
Omega ASCII, Modbus ASCII / RTU
9.5 Isolation
Approvals
UL, C-UL, and CE (8. Approvals Information)
Power to
Input/Output
2300 Vac per 1 min test
1500 Vac per 1 min test (Low-Voltage/Power Option)
Power to Relays/SSR
Outputs
2300 Vac per 1 min test
Relays/SSR to
Relay/SSR Outputs
2300 Vac per 1 min test
RS-232/485 to
Inputs/Outputs
500 Vac per 1 min test
