Omicron Bode 100 User Manual

93
Calibrating the Bode 100
8. Replace the BNC short circuit with the BNC 50 Ω load.
9. For very accurate measurements or if you use a load resistor different from
50 Ω, enter the exact resistance of the load resistor in the respective box in
the Advanced area of the calibration window.
10.Click the Start button next to Load in the Impedance area of the calibration
window. After the calibration has been finished, the field on the right displays
Performed on green background.

Omicron Bode 100 Specifications

General

Brand	Omicron
Model	Bode 100
Category	Measuring Instruments
Language	English
