Omron CK3W-GC 00 Series

To Next Page

To Previous Page

(A)

(C)

(B)

Letter Name Model

A Expansion Master Unit CK3W-EXM01

B Expansion cable CK3W-CAX003A

C Expansion Slave Unit CK3W-EXS02

3 Configuration Units

3-90

CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
