A-2

Dimensions

Dimensions are shown below. The unit of dimension is millimeters.

A-2-1

CPU Unit

8090

63.2

8090

63.2

Appendices

A-4

CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
