Additional Information
To remove Units, perform the steps above in reverse order.
4-3-4
DIN Track and Accessories
Mount the CK3M-series Controller on the DIN Track.
Secure each DIN T
rack inside a control panel with at least three screws.
DIN Tracks
Secure the DIN Track to the control panel using M4 screws separated by 210 mm (3 holes) or less
and using at least 3 screws. The tightening torque is 1.2 N·m.

PFP-100N2
28-25 × 4.5 oblong holes
4.5
1
5 1525
10
10
25 25 25
1000
30±0.3
27
29.2
24
16
1
1.5

PFP-100N/50N
1,000 (500)
*
1
15
1
0
4.5
25 25 25
10
25 15 (5)
*1
1
7.3±0
.15
35±0.3
27±0.15
*1. PFP-50N dimensions are
given in parentheses.
DIN Track End Plates
PFP-M (2 required)
4 Installation
4-13
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
4-3 Unit Installation
4
4-3-4 DIN Track and Accessories
