Omron CK3W-GC 00 Series User Manual

1
Wire
Flat-blade screwdriver
2 Leave the flat-blade screwdriver pressed into the release hole and pull out the wire.
2
3 Remove the flat-blade screwdriver from the release hole.
3
Precautions for Safe Use
• Make sure that all wiring is correct.
• Do not bend the cable forcibly
. Doing so may break the cable.
5-2-4
USB Memory Device Connection
Connect a USB memory device to the USB host port (Type A) on the CPU Unit to save relevant data.
Refer to 3-1-5 USB Memory Device on page 3-9 for information on the recommended USB memory
devices.
5 Wiring
5-17
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
5-2 CPU Unit Wiring
5
5-2-4 USB Memory Device Connection
