Omron CK3W-GC 00 Series - Expansion Master Unit and Expansion Slave Unit Wiring

5-8
Expansion Master Unit and Expan-
sion Slave Unit Wiring
For connection between the Expansion Master Unit and the Expansion Slave Unit, be sure to use the
following expansion cable.
Type Model Length
Expansion cable CK3W-CAX003A 0.3 m
300
5 Wiring
5-50
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
