Omron CK3W-GC 00 Series - A-2-2 Power Supply Unit; A-2-3 Axis Interface Unit

A-2-2
Power Supply Unit
80
90
45
A-2-3
Axis Interface Unit
8090
130
IN
0 1 2 3 4 5 6 7
8 9 10 11 12 13 14 15
0 1 2 3 4 5 6 7
8 9 10 11 12 13 14 15
OUT
Appendices
A-5
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
A-2 Dimensions
A
A-2-2 Power Supply Unit
