Omron CK3W-GC 00 Series User Manual

Installing a Terminal Block
Insert the terminal block into the main body, and press hard to click the terminal block into place on the
Unit.
After you mount the terminal block, make sure that it is fixed to the Unit.
Removing a Terminal Block
Drop the lock levers on both sides of the terminal block at the same time to remove the terminal block.
5 Wiring
5-43
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
5-5 Analog Input Unit Wiring
5
5-5-1 Wiring the Terminals
