1-2
Operating Procedure
This section describes the procedure to construct a motion control system by using the Motion Con-
troller.
No. Step Description Reference
1 Preparation for
work
Check for specifi-
cation compatibili-
ty
Check compatibility with specifications
of each Unit.
• General specifications
• Mounting direction
A-1 General Specifications on
page A-3
Selection of pe-
ripheral devices
Select peripheral devices to be used
with the Motion Controller
.
Preparation of
Support Software
Procure and install the Support Soft-
ware required for the system.
1-1-3 Support Software on page
1-4
2
Mounting and
wiring of the
Motion Control-
ler
Mounting Mount the Motion Controller.
• Connecting adjacent Units
• Mounting to DIN Track
4-3 Unit Installation on page 4-6
Address switch
setting
Set the address switches for the CK3W
Units.
3-3-4 Address Switch Setting on
page 3-16
Wiring Perform Motion Controller
wiring. Section 5 Wiring on page 5-1
3
Settings and
wiring of the
EtherCAT slave
hardware
*1
Node address
settings
Use the hardware switches on all of the
EtherCAT slaves in the network to set
the node addresses.
Refer to the manual for the Ether-
CAT slave.
Mounting
Mount EtherCAT slaves. Refer to the manual for the Ether-
CAT slave.
Wiring Wire EtherCA
T slaves.
• Wiring of the unit power supply
• I/O wiring
Refer to the manual for the Ether-
CAT slave.
4
Installing EtherCAT Communications
Cables
*1
Perform wiring for the EtherCAT com-
munications cables.
5-2-1 Laying the EtherCAT Net-
work on page 5-7
5 Turn ON the power supply to Ether-
CAT slaves.
T
urn on the power to the devices con-
figuring the system.
6 Construction of
the EtherCAT
network
*1
Installation of ESI
files
Install the ESI files of EtherCA
T slaves
to be connected.
Refer to the Power PMAC IDE
User Manual (Cat. No. O016) for
details.
For information on the ESI file, re-
fer to the manual for the EtherCAT
slave.
EtherCAT slave
settings
Configure the EtherCAT communica-
tions settings.
Then, create an ENI file used to down-
load the configured settings to the Mo-
tion Controller
.
Refer to the Power PMAC IDE
User Manual (Cat. No. O016) for
details.
Activation of the
EtherCAT network
Use Power PMAC IDE to download the
ENI file to the Motion Controller.
Make sure that the ENI file has been
correctly downloaded, and then activate
the EtherCA
T network.
Refer to the Power PMAC IDE
User Manual (Cat. No. O016) for
details.
1 Introduction to Motion Controllers
1-5
CK3M-series Programmable Multi-Axis Controller User's Manual Hardware (O036)
1-2 Operating Procedure
