Exchanging Data with the CPU Unit Section 7-5
DM Allocation Contents The following table shows the allocation of DM words and bits for both normal
and adjustment mode.
DM word Bits
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
D(m) Ratio conversion use setting Input use setting Output use setting
Not used. Not used. Loop 2 Loop 1 Input
4
Input
3
Input
2
Input
1
Not
used.
Not
used.
Out-
put 2
Out-
put 1
D(m+1) Input signal range setting Output signal range setting
Input 4 Input 3 Input 2 Input 1 Not used. Not used. Output 2 Output 1
D(m+2) Not used. Output 1: Output status when conversion stopped
D(m+3) Not used. Output 2: Output status when conversion stopped
D(m+4) Not used.
D(m+5) Not used.
D(m+6) Input 1: Mean value processing setting
D(m+7) Input 2: Mean value processing setting
D(m+8) Input 3: Mean value processing setting
D(m+9) Input 4: Mean value processing setting
D(m+10) Loop 1 (input 1 to output 1), A constant
D(m+11) Loop 1 (input 1 to output 1), B constant
D(m+12) Loop 2 (input 2 to output 2), A constant
D(m+13) Loop 2 (input 2 to output 2), B constant
D(m+14) Not used.
D(m+15) Not used.
D(m+16) Not used.
D(m+17) Not used.
D(m+18) Conversion time and resolution setting Operation mode setting
D(m+19) Output 1 scaling lower limit (Enabled only for conversion time of 1 ms and resolution of 4,000.)
D(m+20) Output 1 scaling upper limit (Enabled only for conversion time of 1 ms and resolution of 4,000.)
D(m+21) Output 2 scaling lower limit (Enabled only for conversion time of 1 ms and resolution of 4,000.)
D(m+22) Output 2 scaling upper limit (Enabled only for conversion time of 1 ms and resolution of 4,000.)
D(m+23) Not used.
D(m+24) Not used.
D(m+25) Not used.
D(m+26) Not used.
D(m+27) Input 1 scaling lower limit
D(m+28) Input 1 scaling upper limit
D(m+29) Input 2 scaling lower limit
D(m+30) Input 2 scaling upper limit
D(m+31) Input 3 scaling lower limit
D(m+32) Input 3 scaling upper limit
D(m+33) Input 4 scaling lower limit
D(m+34) Input 4 scaling upper limit
D(m+35) Voltage/current range setting (Enabled only when set for 1 to 5 V, 4 to 20 mA)
Not used. Input
4
Input
3
Input
2
Input
1
Not used. Out-
put 2
Out-
put 1
