Omron CS1W-AD081-V1

27
Components and Switch Settings Section 2-3
2-3 Components and Switch Settings
Unit number
setting switch
External
terminal
block (M3)
Front
With Terminal Block With Terminal Block Removed
Voltage/
Current
switch
CS1W-AD041-V1 CS1W-AD081-V1
Unit number
setting switch
External
terminal
block (M3)
Front
Voltage/
Current
switch
External
terminal block
mounting
screws
(black M3)
External
terminal block
mounting
screws
(black M3)
With Terminal Block With Terminal Block Removed
Operation mode switch
Backplane connector
Terminal block
Side
Back
